92.70.134.00

  • 92.70.134.00

Products

4-2273-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

4-2273-M

Diameter: 111 mm
Height: 64.6 mm
Add
LED Light Source Angle Accessory
Tridonic SLE G7 13MM 10° 92.70.131.00
Tridonic SLE G7 15MM 11° 92.70.131.00
SEOUL SAWx15 11° 92.70.131.00
OSRAM OPTO SOLERIQ S19 12° 92.70.134.00
OSRAM OPTO SOLERIQ S15 11° 92.70.131.00
OSRAM OPTO SOLERIQ S13 92.70.131.00
Nichia NFCWJ120B-V3 11° 92.70.135.00
Nichia NVEWJ048Z-V1 11° 92.70.135.00
Nichia NFCWJ108B-V3 11° 92.70.135.00
Nichia NFCWD096B-V3 10° 92.70.135.00
Cree CMT1922 11° 92.70.131.00
Lumileds LUXEON CoB 1208 11° 92.70.135.00
Luminus CXM-11-AC30 92.70.131.00
Nichia NFCWD084B-V2 11° 92.70.135.00
Luminus CXM-14-AC40 12° 92.70.131.00
Cree CXA1830 11° 92.70.129.00
Cree CXA2520 13° 92.70.134.00
Cree CXA1820 92.70.129.00
Citizen CLU038 11° 92.70.131.00
BMTC MA-1919 20W 12° 92.70.131.00
Bridgelux V13B 11° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 11° 92.70.135.00
Bridgelux V9-HD 92.70.131.00
4-2275-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

4-2275-M

Diameter: 111 mm
Height: 64.1 mm
Add
LED Light Source Angle Accessory
SEOUL SAWx15 19° 92.70.131.00
Philips SLM 1208 G7 L15 20° 92.70.131.00
Philips SLM 1205 G7 L13 20° 92.70.131.00
OSRAM OPTO SOLERIQ S15 20° 92.70.131.00
OSRAM OPTO SOLERIQ S19 23° 92.70.134.00
OSRAM OPTO SOLERIQ S13 19° 92.70.131.00
Nichia NFCWJ108B-V3 21° 92.70.135.00
Nichia NFCWD096B-V3 20° 92.70.135.00
Luminus CXM-11-AC30 19° 92.70.131.00
Luminus CXM-14-AC40 21° 92.70.131.00
Nichia NFCWD084B-V2 18° 92.70.135.00
Nichia NFCWJ120B-V3 20° 92.70.135.00
Lumileds LUXEON CoB 1208 18° 92.70.135.00
Nichia NVEWJ048Z-V1 19° 92.70.135.00
Lumileds LUXEON CoB 1205 17° 92.70.135.00
Cree CMT1922 20° 92.70.131.00
Bridgelux V13B 18° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 19° 92.70.135.00
BMTC MA-1919 20W 20° 92.70.131.00
Citizen CLU038 18° 92.70.131.00
Cree CXA1820 18° 92.70.129.00
Cree CXA2520 22° 92.70.134.00
Bridgelux V9-HD 18° 92.70.131.00
3-2046-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-2046-M

Diameter: 95 mm
Height: 55.2 mm
Add
LED Light Source Angle Accessory
Bridgelux BXRV-DR-1830-H-3000-A-13 35° 92.70.135.00
Tridonic SLE G7 15MM 33° 92.70.131.00
Tridonic SLE G7 13MM 30° 92.70.131.00
OSRAM OPTO SOLERIQ S19 38° 92.70.134.00
SEOUL SAWx15 35° 92.70.131.00
Nichia NFCWD096B-V3 32° 92.70.135.00
Nichia NFCWJ108B-V3 35° 92.70.135.00
Nichia NFCWD084B-V2 33° 92.70.135.00
Nichia NFCWJ120B-V3 34° 92.70.135.00
OSRAM OPTO SOLERIQ S13 30° 92.70.131.00
OSRAM OPTO SOLERIQ S15 32° 92.70.131.00
Nichia NVEWJ048Z-V1 35° 92.70.135.00
BMTC MA-1919 20W 36° 92.70.131.00
Luminus CXM-11-AC30 29° 92.70.131.00
Cree CMT1922 33° 92.70.131.00
Cree CXA1830 35° 92.70.129.00
Citizen CLU038 34° 92.70.131.00
Bridgelux V13B 34° 92.70.131.00
3-2042-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-2042-M

Diameter: 95 mm
Height: 55 mm
Add
LED Light Source Angle Accessory
Tridonic SLE G7 15MM 15° 92.70.131.00
BMTC MA-1919 20W 14° 92.70.131.00
Tridonic SLE G7 13MM 12° 92.70.131.00
SEOUL SAWx15 14° 92.70.131.00
OSRAM OPTO SOLERIQ S19 16° 92.70.134.00
OSRAM OPTO SOLERIQ S15 13° 92.70.131.00
OSRAM OPTO SOLERIQ S13 12° 92.70.131.00
Nichia NVEWJ048Z-V1 14° 92.70.135.00
Nichia NFCWJ108B-V3 14° 92.70.135.00
Nichia NFCWD096B-V3 13° 92.70.135.00
Nichia NFCWD084B-V2 13° 92.70.135.00
Nichia NFCWJ120B-V3 14° 92.70.135.00
Lumileds LUXEON CoB 1208 14° 92.70.135.00
Luminus CXM-11-AC30 11° 92.70.131.00
Cree CMT1922 14° 92.70.131.00
Lumileds LUXEON CoB 1205 14° 92.70.135.00
Cree CXA1830 13° 92.70.129.00
Citizen CLU038 13° 92.70.131.00
Cree CXA1820 11° 92.70.129.00
Bridgelux V9-HD 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 13° 92.70.135.00
Bridgelux V13B 12° 92.70.131.00
2-1738-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

2-1738-M

Diameter: 75 mm
Height: 43.2 mm
Add
LED Light Source Angle Accessory
Cree CXA2520 20° 92.70.134.00
Bridgelux V22B 25° 92.70.136.00
Cree CMT2850 26° 92.70.136.00
Cree CXA3050 25° 92.70.136.00
Citizen CLU044 25° 92.70.136.00
3-2040-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-2040-M

Diameter: 85 mm
Height: 51 mm
Add
LED Light Source Angle Accessory
BMTC MA-1919 30W 21° 92.70.131.00
Tridonic SLE G7 15MM 20° 92.70.131.00
Tridonic SLE G7 13MM 20° 92.70.131.00
SEOUL SAWx15 21° 92.70.131.00
BMTC MA-1919 20W 21° 92.70.131.00
OSRAM OPTO SOLERIQ S13 19° 92.70.131.00
OSRAM OPTO SOLERIQ S15 21° 92.70.131.00
Luminus CXM-14-AC40 22° 92.70.131.00
Nichia NFCWD084B-V2 20° 92.70.135.00
Lumileds LUXEON CoB 1208 23° 92.70.135.00
Luminus CXM-11-AC30 19° 92.70.131.00
Nichia NFCWJ108B-V3 21° 92.70.135.00
Nichia NFCWD096B-V3 20° 92.70.135.00
Citizen CLU038 22° 92.70.131.00
Cree CXA1820 21° 92.70.129.00
OSRAM OPTO SOLERIQ S19 22° 92.70.134.00
Nichia NVEWJ048Z-V1 21° 92.70.135.00
Nichia NFCWJ120B-V3 21° 92.70.135.00
Cree CMT1922 21° 92.70.131.00
Lumileds LUXEON CoB 1205 23° 92.70.135.00
Cree CXA1830 22° 92.70.129.00
Bridgelux V9-HD 18° 92.70.131.00
Bridgelux V13B 22° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 22° 92.70.135.00
3-1648-E,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-1648-E

Diameter: 85 mm
Height: 70 mm
Add
LED Light Source Angle Accessory
Cree CXA2520 34° 92.70.134.00
3-2033-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-2033-M

Diameter: 85 mm
Height: 51.2 mm
Add
LED Light Source Angle Accessory
Tridonic SLE G7 13MM 15° 92.70.131.00
OSRAM OPTO SOLERIQ S15 14° 92.70.131.00
Nichia NFCWD096B-V3 14° 92.70.135.00
Tridonic SLE G7 15MM 15° 92.70.131.00
OSRAM OPTO SOLERIQ S19 16° 92.70.134.00
SEOUL SAWx15 15° 92.70.131.00
OSRAM OPTO SOLERIQ S13 13° 92.70.131.00
Nichia NFCWJ108B-V3 15° 92.70.135.00
Lumileds LUXEON CoB 1208 16° 92.70.135.00
Nichia NVEWJ048Z-V1 15° 92.70.135.00
Nichia NFCWJ120B-V3 15° 92.70.135.00
Nichia NFCWD084B-V2 14° 92.70.135.00
Luminus CXM-11-AC30 13° 92.70.131.00
Cree CXA1830 14° 92.70.129.00
Cree CMT1922 15° 92.70.131.00
Bridgelux V13B 14° 92.70.131.00
Luminus CXM-14-AC40 16° 92.70.131.00
Lumileds LUXEON CoB 1205 15° 92.70.135.00
Cree CXA1820 13° 92.70.129.00
BMTC MA-1919 30W 15° 92.70.131.00
Citizen CLU038 14° 92.70.131.00
BMTC MA-1919 20W 15° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 15° 92.70.135.00
Bridgelux V9-HD 11° 92.70.131.00
3-1647-E,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-1647-E

Diameter: 85 mm
Height: 70 mm
Add
LED Light Source Angle Accessory
Cree CXA2520 24° 92.70.134.00
3-1646-E,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-1646-E

Diameter: 85 mm
Height: 70 mm
Add
LED Light Source Angle Accessory
Cree CXA2520 18° 92.70.134.00
3-2035-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-2035-M

Diameter: 85 mm
Height: 54.8 mm
Add
LED Light Source Angle Accessory
Tridonic SLE G7 13MM 43° 92.70.131.00
OSRAM OPTO SOLERIQ S19 42° 92.70.134.00
Tridonic SLE G7 15MM 43° 92.70.131.00
SEOUL SAWx15 42° 92.70.131.00
Bridgelux V13B 42° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 43° 92.70.135.00
OSRAM OPTO SOLERIQ S15 43° 92.70.131.00
Nichia NFCWD096B-V3 43° 92.70.135.00
OSRAM OPTO SOLERIQ S13 43° 92.70.131.00
Nichia NVEWJ048Z-V1 43° 92.70.135.00
Nichia NFCWJ108B-V3 43° 92.70.135.00
Nichia NFCWJ120B-V3 43° 92.70.135.00
Cree CMT1922 43° 92.70.131.00
Lumileds LUXEON CoB 1205 41° 92.70.135.00
Nichia NFCWD084B-V2 43° 92.70.135.00
Luminus CXM-14-AC40 42° 92.70.131.00
Luminus CXM-11-AC30 43° 92.70.131.00
Cree CXA1820 42° 92.70.129.00
Cree CXA1830 42° 92.70.129.00
Lumileds LUXEON CoB 1208 43° 92.70.135.00
BMTC MA-1919 20W 42° 92.70.131.00
Citizen CLU038 42° 92.70.131.00
Bridgelux V9-HD 42° 92.70.131.00
2-1740-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

2-1740-M

Diameter: 75 mm
Height: 43 mm
Add
LED Light Source Angle Accessory
Cree CMT2850 36° 92.70.136.00
Cree CXA3050 36° 92.70.136.00
Cree CXA2520 30° 92.70.134.00
Bridgelux V22B 36° 92.70.136.00
Citizen CLU044 36° 92.70.136.00
3-2044-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

3-2044-M

Diameter: 95 mm
Height: 55.2 mm
Add
LED Light Source Angle Accessory
Tridonic SLE G7 15MM 28° 92.70.131.00
Tridonic SLE G7 13MM 25° 92.70.131.00
OSRAM OPTO SOLERIQ S19 30° 92.70.134.00
Nichia NFCWD096B-V3 26° 92.70.135.00
Nichia NVEWJ048Z-V1 26° 92.70.135.00
Cree CMT1922 26° 92.70.131.00
Lumileds LUXEON CoB 1205 25° 92.70.135.00
Lumileds LUXEON CoB 1208 27° 92.70.135.00
SEOUL SAWx15 26° 92.70.131.00
Bridgelux V13B 25° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 26° 92.70.135.00
OSRAM OPTO SOLERIQ S13 25° 92.70.131.00
Nichia NFCWJ108B-V3 27° 92.70.135.00
Nichia NFCWJ120B-V3 27° 92.70.135.00
Nichia NFCWD084B-V2 25° 92.70.135.00
Luminus CXM-11-AC30 24° 92.70.131.00
OSRAM OPTO SOLERIQ S15 26° 92.70.131.00
Cree CXA1830 25° 92.70.129.00
Citizen CLU038 25° 92.70.131.00
2-1742-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

2-1742-M

Diameter: 75 mm
Height: 43.2 mm
Add
LED Light Source Angle Accessory
Cree CXA2520 40° 92.70.134.00
Bridgelux V22B 40° 92.70.136.00
Cree CMT2850 43° 92.70.136.00
Cree CXA3050 40° 92.70.136.00
Citizen CLU044 40° 92.70.136.00
4-2267-M,lens, reflectors, aluminum reflectors, light reflectors, LED reflectors, LED reflector design, LED spot reflectors

4-2267-M

Diameter: 111 mm
Height: 64.2 mm
Add
LED Light Source Angle Accessory
OSRAM OPTO SOLERIQ S19 40° 92.70.134.00
Tridonic SLE G7 15MM 36° 92.70.131.00
Bridgelux BXRV-DR-1830-H-3000-A-13 35° 92.70.135.00
Luminus CXM-14-AC40 36° 92.70.131.00
OSRAM OPTO SOLERIQ S15 33° 92.70.131.00
OSRAM OPTO SOLERIQ S13 32°
Nichia NFCWD096B-V3 33° 92.70.135.00
Nichia NFCWJ108B-V3 35° 92.70.135.00
Nichia NFCWJ120B-V3 35° 92.70.135.00
Nichia NVEWJ048Z-V1 35° 92.70.135.00
Nichia NFCWD084B-V2 33° 92.70.135.00
Cree CMT1922 35° 92.70.131.00
Lumileds LUXEON CoB 1205 33° 92.70.135.00
Lumileds LUXEON CoB 1208 35° 92.70.135.00
SEOUL SAWx15 34° 92.70.131.00
Luminus CXM-11-AC30 30° 92.70.131.00
Cree CXA2520 40° 92.70.134.00
Cree CXA1816 29° 92.70.129.00
Citizen CLU038 35° 92.70.131.00
BMTC MA-1919 20W 34° 92.70.131.00
Tridonic SLE G7 13MM 33° 92.70.131.00
Bridgelux V9-HD 24° 92.70.131.00
Bridgelux V13B 32° 92.70.131.00
